Welcome to KingPo

IP1-7 Comprehensive Water Spray Test Chamber with Calibration Certificate

Place Of Origin:Guangdong, China (Mainland)Interior Material:SUS304#stainless Frosting Steel Sheet / Subject To Acquirer’s Decoration
Exterior Material:SUS202#stainless Steel Sheet / Subject To Acquirer’s DecorationWater Source And Energy:Purified/distilled Water 500L/day
Spray System:One IP5 Spray Nozzle,one IP6 Spray Nozzle,2000 IP1234 Spray NozzlesSpray Angle:Perpendicular To Sample
Power And Voltage:3KW 380V 3Phase
Highlight:ozone test chamber

climatic test chamber

IP1-7 Comprehensive Water Spray Test Chamber

  • Product Details
  • Inquiry

Product Description



IP1-7 Comprehensive Water Spray Test Chamber





Function Description



The chamber is applicable to check whether the device and components are ensured good performance when electrical product and its outer case are sealed in a raining environment,which is of scientific design and vividly simulate various environment like torrential rain and fierce water spray.Comprehensive stepping control system and stepping technique make 360°rotation of rainfall sample rack and rotary table to simulate a fiercely raining environment from all aspects.



Technical Parameter



typeKP-IP1-7-1 box typeKP-IP1-7-56F
Pendulum spray bore diameterIP1234 spray bore¢0.4MM ,IP56 spray bore:¢6.5MM ,¢12.5MM
Distance between spray bore and sampleIP1234:200mm IP56:2500-3000mm
Turntable diameter and speed¢300, ¢500 3r±1/Min
Spray flowIP1234 the same as box type IP5-12.5L/Min IP6-12.5L/Min
Spray pressure80-150KPA80-150KPA
Test time0~999h 59min0~999h 59min
Interior dimensionD800 X W800 X H2700MMD4000 X W5000 X H2800MM
Exterior dimensionD1000 X W1300 X H3500mmSubject to acquirer’s decoration
Interior materialSUS304#stainless frosting steel sheetSubject to acquirer’s decoration
Exterior materialSUS202#stainless steel sheetSubject to acquirer’s decoration
Water source and energypurified/distilled water 500L/day
controllerIndependent R&D PLC touch screen controllerIndependent R&D PLC touch screen controller
Spray systemOne IP5 spray nozzle,oneIP6 spray nozzle,2000 IP1234 spray nozzles
Spray angleperpendicular to sample
Power and voltage3KW 380V 3Phase
