AD360 Test Rotary Table Used For The Directivity Test Of The ENC Noise Reduction Characteristics Of Speakers, Loudspeaker Box, Microphones And Earphones
- Product Details
- Inquiry
AD360 is an electric integrated rotary table, which can control the rotation angle through the driver to realize the multi-angle directivity test of the product. The rotary table is built with a balanced force structure, which can carry tested products smoothly.,It is specially used for the directivity test of the ENC noise reduction characteristics of speakers, loudspeaker box, microphones and earphones.
Performance Parameters
| Performance Specifications | |
| Operating Conditions | Rotate Horizontally , Place Vertically |
| Running Direction | Counterclockwise / Clockwise |
| Allowable Axial Load | 500kg |
| Allowable Radial Load | 300kg |
| Continuous Torque | 1.2 N.M _ |
| Peak Torque | 2.0 N.M _ |
| Positioning Accuracy | 0.1° |
| Rotation Range | 0 – 360° |
| Range Of Rotation Rate | 0.1 – 1800rpm |
| Physical Parameters | |
| Operating Voltage | DC: 12V |
| Control Method | Software Control & Physical Buttons |
| Rotary Table Diameter | Φ400mm |
| Top Mounting Hole | M5 |
| Dimensions ( W×D×H ) | 455mmX460mmX160mm |
| Weight | 28.8kg |
