Ad2536 Audio Analyzer With 8-Channel Analog Output, 16-Channel Analog Input Interface
- Product Details
- Inquiry
AD2536 is a multi-channel precision test instrument derived from AD2528. It is a true multi-channel audio analyzer. Standard configuration 8-channel analog output, 16-channel analog input interface, can achieve up to 16-channel parallel testing. The input channel can withstand a peak voltage of 160V, which provides a more convenient and faster solution for simultaneous testing of multi-channel products. It is the best choice for production testing of multi-channel power amplifiers.In addition to the standard analog ports, AD2536 can also be equipped with various extended modules such as DSIO, PDM, HDMI, BT DUO and digital interfaces. Realize multi-channel, multi-function, high efficiency and high precision
Key Features
◆ Signal source residual THD+N ＜ -106dB
◆ Analog 8 -channel output, 16 -channel input, true multi-channel audio analyzer
◆ Support digital interface expansion such as BT /HDMI+ARC/I2S/ PDM
◆ Complete and powerful electroacoustic analyzer functions
◆ Code-free, complete a comprehensive test within 3 seconds
◆ Support LabVIEW , VB.NET , C#.NET , Python and other languages for secondary development
◆ Automatically generate test reports in various formats
◆ Support Dolby&DTS digital stream playback
Performance
| Analog Output | |
| Number Of Channels | 8 Channels, Balanced / Unbalanced |
| Signal Type | Sine Wave, Dual-Frequency Sine Wave, Out-Of-Phase Sine Wave, Frequency Sweep Signal, Noise Signal, WAVE File |
| Frequency Range | 0.1Hz ~ 80.1kHz |
| Frequency Accuracy | ± 0.0003% |
| Residual THD+N | ＜ -106dB @ 20kHz BW |
| Output Voltage | Balance 0 ~ 14.4Vrms; Unbalanced 0 ~ 7.2Vrms |
| Flatness | <-106dB @20KHz BW |
| Analog Input | |
| Number Of Channels | 16 Channels , Balanced / Unbalanced |
| Maximum Input Voltage | 160Vpk |
| Residual Input Noise | < 1.3 UV @ 20kHz BW |
| Maximum FFT Length | 1248k |
| Frequency Measurement Range | 5Hz ~ 90kHz |
| Frequency Measurement Accuracy | ± 0.0003% |
| Input Resistance | Balance：200kohm，Unbalance:100kohm |
| Voltage Measurement Flatness | 0.01dB(20Hz~20kHz) |
| Single Harmonic Analysis | 2 Times To 10 Times |
| Residual Input Noise | <1.3 UV@ 20kHz BW |
| Intermodulation Distortion Pattern | SMPTE. MOD. DPD |
| Phase Measurement Range | 90°~270°，±180°，0~360° |
| DC Voltage Measurement | Support |
